| Parameter | 100W | 135W | 200W | 350W | 400W | 450W | 500W |
|---|---|---|---|---|---|---|---|
| Peak Power (Pmax) | 100W | 135W | 200W | 350W | 400W | 450W | 500W |
| Maximum Power Voltage (Vmp) | 11.27V | 15.59V | 22.53V | 40.1V | 45.1V | 50.68V | 56.31V |
| Maximum Power Current (Imp) | 8.88A | 8.66A | 8.88A | 8.73A | 8.87A | 8.88A | 8.88A |
| Open Circuit Voltage (Voc) | 13.29V | 18.40V | 26.56V | 47.51V | 53.17V | 59.15V | 66.39V |
| Short Circuit Current (Isc) | 9.39A | 9.15A | 9.39A | 9.25A | 9.38A | 9.39A | 9.39A |
| Module Efficiency (%) | 18.47% | 18.46% | 19.45% | 19.5% | 20.11% | 20.15% | 20.21% |
| Thermal Characteristics & Operating Conditions | |||||||
| Maximum System Voltage (V) | 1000V | ||||||
| Maximum Series Fuse Rating (A) | 10A | ||||||
| Power Tolerance | 0~+3% | ||||||
| Pmax Temperature Coefficients | -0.400%/°C | ||||||
| Voc Temperature Coefficients | -0.330%/°C | ||||||
| Isc Temperature Coefficients | +0.048%/°C | ||||||
| NOCT Nominal Operating Cell Temp | 45±2°C | ||||||
| Operating & Storage Temp | -40°C ~ +85°C | ||||||
| Mechanical Characteristics | |||||||
| Cell Type | 210*105 Mono | ||||||
| No. of Cells | 20 (4*5) | ||||||
| Dimensions | 900*595*3mm | ||||||
| Weight | 1.98kg / 2.67kg / 3.75kg / 6.55kg / 7.26kg / 8.15kg / 9.03kg | ||||||
| Junction Box | IP65 / IP67 | ||||||
| Output Cables | 2.5mm² cables 50cm + MC4 connectors | ||||||
| Max Wind / Snow Load | 2400Pa / 5400Pa | ||||||
