Halkirk Solar
1 / 5
| Module Type | BSM710G12-66HNH | BSM715G12-66HNH | BSM720G12-66HNH | |||
|---|---|---|---|---|---|---|
| STC | NMOT | STC | NMOT | STC | NMOT | |
| Maximum Power(Pmax/W) | 710 | 542 | 715 | 546 | 720 | 550 |
| Operating Voltage(Vmp/V) | 40.9 | 38.2 | 41.1 | 38.4 | 41.3 | 38.6 |
| Operating Current(Imp/A) | 17.37 | 14.19 | 17.41 | 14.22 | 17.45 | 14.25 |
| Open-Circuit Voltage(Voc/V) | 48.6 | 46.1 | 48.8 | 46.3 | 49 | 46.5 |
| Short-Circuit Current(Isc/A) | 18.4 | 14.88 | 18.44 | 14.92 | 18.48 | 14.96 |
| Module Efficiency(nm%) | 22.86 | 23.02 | 23.18 | |||
| Electrical characteristics with different rear side power gain | |||||
|---|---|---|---|---|---|
| Power Gain | 5% | 10% | 15% | 20% | 25% |
| Maximum Power (Pmax/W) | 730 | 765 | 799 | 834 | 869 |
| Open-Circuit Voltage(Voc/V) | 47.90 | 47.90 | 47.90 | 48.00 | 48.00 |
| Operating Voltage(Vmp/V) | 40.30 | 40.30 | 40.30 | 40.40 | 40.40 |
| Short-Circuit Current(Isc/A) | 18.84 | 19.56 | 20.25 | 20.98 | 21.69 |
| Operating Current(Imp/A) | 18.12 | 18.99 | 19.83 | 20.65 | 21.51 |
| Payment Term | Method | Trade Clause | Detail Conditions |
|---|---|---|---|
| Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment |
| FOB | |||
| CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||
| CIF | |||
| L/C | L/C | All | L/C amount above 50,000 USD, we can accept L/C at sight |
| West Union | West Union | All | Amount lower than 5000 USD |
| Delivery Time | 7~ 10 days after receiving payment for one container | ||
