Environmentally friendly building materials. The combination of traditional building materials and thin-film solar technology can not only replace traditional tiles as building materials, but also replace traditional photovoltaic panels.
Solar tile not only has the functions of waterproofing and heat insulation, but also changes the dependence of buildings on external energy sources, making zero-energy buildings possible.
| Physical Parameters | |
| Product Model | BSM-30S |
| Length | 700mm |
| Width | 500mm |
| Arch Height | 35mm |
| Weight | 5.2KG |
| Color | Black |
| Junction Box | 68*68*19.7 (mm) IP67 |
| Cable Type | 2.5mm solar cable 450 (+10/-0) mm |
| Cable Connector | PV connector |
| Electrical Parameters | |
| Chip Type | CIGS |
| Power | 30W |
| Short-circuit Current | 4.45A |
| Open-circuit Voltage | 10.16V |
| Current at PMPP | 3.87A |
| Voltage at PMPP | 7.79V |
| Function Grade | |
| Loading Grade | 2400Pa |
| Waterproof Grade | IP67 |
| Fire-proof Grade | B1 |
| Hail-proof Grade | Level 4 (ANSI FM 4473) |
| Working Temperature | -40°C to +85°C |
| Package | Packing Specification | Gross Weight | Net Weight | Number Per Carton |
|---|---|---|---|---|
| One Box | 1260X780X690mm | 492kg | 442kg | 68pcs |
| Container Plan | Loading Quantity (Cartons) | Loading Quantity (Pieces) | Total Weight | Volume |
|---|---|---|---|---|
| 20ft | 18ctn | 1224pcs | 8.86t | 27.6m³ |
| 40ft | 42ctn | 2856pcs | 20.66t | 54m³ |
| Payment Term | Method | Condition Details |
|---|---|---|
| T/T | EXW | 30% T/T in advance, balance paid before shipment |
| FOB | ||
| CFR (C&F) | 30% T/T in advance, balance paid against copy of B/L | |
| CIF | ||
| L/C | L/C at sight | Acceptable for order amount above 50,000 USD |
| Western Union | West Union | Acceptable for order amount lower than 5,000 USD |
| Delivery Time | 7 ~ 10 days after receiving payment for one container | |
A solar tile is an environmentally friendly building material that combines traditional roofing tile functionality with thin-film solar technology. It replaces conventional tiles and standard solar panels, offering waterproofing, heat insulation, and zero-energy building possibilities.
The BSM-30S is a 30W CIGS chip thin-film solar tile measuring 700mm in length, 500mm in width, with an arch height of 35mm. It weighs 5.2kg, has an IP67 rated junction box, and features a short-circuit current of 4.45A with an open-circuit voltage of 10.16V.
These solar tiles have high durability ratings: a wind/snow loading grade of 2400Pa, an IP67 waterproof grade, a B1 fire-proof rating, and level 4 hail-proof certification (ANSI FM 4473). They operate reliably in temperatures ranging from -40°C to +85°C.
Each carton contains 68 pieces with dimensions of 1260x780x690mm (Gross Weight: 492kg). For bulk shipping, a 20ft container loads 18 cartons (1,224 pieces) and a 40ft container loads 42 cartons (2,856 pieces).
We accept T/T payments (30% in advance with remaining balance paid before shipment or against copy of B/L), L/C at sight (for orders above 50,000 USD), and Western Union (for payments under 5,000 USD). Standard delivery time is 7 to 10 days per container after payment.
