| Model of Solar Panel | RS610M-156HC | RS615M-156HC | RS620M-156HC | RS625M-156HC | RS630M-156HC |
| Peak Power Watts-Pmax(Wp)* | 610 | 615 | 620 | 625 | 630 |
| Maximum Power Voltage-Vmpp(V) | 45.60 | 45.70 | 45.80 | 45.93 | 46.03 |
| Maximum Power Current-Impp(A) | 13.38 | 13.46 | 13.54 | 13.61 | 13.69 |
| Open Circuit Voltage-Voc(V) | 55.25 | 55.40 | 55.55 | 55.70 | 55.85 |
| Short Circuit Current-Isc(A) | 14.11 | 14.18 | 14.25 | 14.32 | 14.39 |
| Module Efficiency (%) | 21.82 | 22.0 | 22.18 | 22.36 | 22.54 |
| Power Output Tolerance-Pmax(W) | 0~+5 | ||||
| Temperature Coefficient of Pmax | -0.29%/ºC | ||||
| Temperature Coefficient of Voc | -0.25%/ºC | ||||
| Temperature Coefficient of Isc | 0.045%/ºC | ||||
| STC | Irradiance 1000W/m2, Cell Temperature 25, Air Mass AM1.5 | ||||
