| MECHANICAL SPECIFICATIONS | |
|---|---|
| Cell Type | N TOPCon Monocrystalline |
| Weight | 38KG |
| Dimensions | 2384*1303*33mm |
| Cable Length | Portrait 300mm/Landscape 1200mm/Customized |
| Cable Cross Section Size | TUV: 4mm2 (0.006inches2)/UL: 12AWG |
| No. of Bypass Diodes | 3/6 |
| ELECTRICAL SPECIFICATIONS (STC Testing Condition) | |||||
|---|---|---|---|---|---|
| Rated output (Pmp/Wp) | 700 | 705 | 710 | 715 | 720 |
| Maximum Power Voltage(Vmpp/V) | 42.1 | 42.30 | 42.4 | 42.5 | 42.7 |
| Maximum Power Current(Impp/A) | 16.63 | 16.69 | 16.75 | 16.81 | 16.87 |
| Open Circuit Voltage(Voc/V) | 50.1 | 50.3 | 50.4 | 50.6 | 50.7 |
| Short Circuit Current(Isc/A) | 17.43 | 17.49 | 17.55 | 17.61 | 17.67 |
| Module efficiency(%) | 22.53% | 22.70% | 22.86% | 23.02% | 23.18% |
| Power Tolerance (W) | 0~+5 | ||||
| Temperature Coefficient (Pmax) | -0.26%/℃ | ||||
| Temperature Coefficient (Voc) | -0.24%/℃ | ||||
| Temperature Coefficient (Isc) | 0.040%/℃ | ||||
