Premium solar panels are designed to maximize energy efficiency and deliver substantial cost savings for residential and commercial applications. Our photovoltaic solar panel systems harness renewable solar energy to reduce electricity bills and carbon footprint while providing reliable, sustainable power generation.
| TECHNICAL PARAMETERS | |
|---|---|
| Product Name | Solar panel glass plate YTXN-33M-100W |
| Keywords | Solar Panel |
| Max. Power | 100W |
| Open circuit voltage(Voc) | 21.4V |
| Short circuit current(lsc) | 6.08A |
| Max power voltage(Vmp) | 18V |
| Max power current(lmp) | 5.75A |
| Module Efficiency(%) | 21.64% |
| Power Tolerance | 0-+3W |
| Operation temperature | -40℃~+85℃ |
| Cells Type | Mono-crystalline |
| No.of Cell | 33(3*11) |
| Weight | 1.3KG |
| Dimensions | 1000*540*2mm |
| Front Cover Single Glass | 3.2mm tempered glass,with anti-reflection coating |
